A core drilling rig is a type of core drilling equipment. It is mainly used for the general survey and exploration of metallic and non-metallic solid minerals. In addition, it can also be used for engineering geological exploration, hydrogeological survey, general survey and exploration of oil and gas fields, and water well drilling.
Get A Quote Now
| Vertical shaft core drilling rig | |||
|---|---|---|---|
| Model | YG-130 | YG-180 | YG-200 |
| Drilling depth (m) | 130 | 180 | 200 |
| Open hole dia. (mm) | 220 | 220 | 325 |
| End hole dia. (mm) | 75 | 75 | 75 |
| Drill angle (°) | 90-75 | 90-75 | 90-75 |
| Matching power (kw) | 13.2 | 13.2 | 15 |
| Fully hydraulic core drilling rig | ||||
|---|---|---|---|---|
| Model | YG-400 | YG-600 | YG-800 | YG-1000 |
| Drilling depth (m) | 400 | 600 | 800 | 1000 |
| Drilling diameter (mm) | 60-110 | 60-110 | 60-110 | 60-110 |
| Overall weight (T) | 5.3 | 6.7 | 8.1 | 9.2 |
| Main machine power (kw) | 75 | 96 | 118 | 132 |
| Wheel core drilling rig | |
|---|---|
| Parameter | Value |
| Drilling depth (m) | 100、250、300、600 |
| Drilling diameter (mm) | 300、200、150、75 |
| Opening diameter (mm) | 300 |
| Final hole diameter (mm) | 75 |
| Drill pipe (mm) | 60 |
| Truck-mounted core drilling rig | ||
|---|---|---|
| Model | XYC-200GT | XYC-3 |
| Drilling depth (m) | 30-200 | 30-600 |
| Opening hole dia. (mm) | 75-300 | 75-300 |
| Drill rig weight (kg) | 970 | 1800 |
| Spindle speed | 64-557r/min | 30-1050r/min |
| Spindle stroke (mm) | 450 | 600 |
| Diesel engine power (rpm) | 14.7kw/2200 | 39kw/2400 |
The control functions are concentrated on the console, which facilitates operation and saves time and effort.
Wireless remote-controlled crawler chassis adapts to various terrains and enables safe remote rig movement.
The compact body with reasonable design ensures flexibility, durability, and easy operation.
Prevent accidental detachment of the rod and provide strong propulsion force.
